Expanding into New Frontiers - Smart DNS Proxying in Istio
Use workload-local DNS resolution to simplify VM integration, multicluster, and more
DNS resolution is a vital component of any application infrastructure
on Kubernetes. When your application code attempts to access another
service in the Kubernetes cluster or even a service on the internet,
it has to first lookup the IP address corresponding to the hostname of
the service, before initiating a connection to the service. This name
lookup process is often referred to as service discovery. In
Kubernetes, the cluster DNS server, be it
kube-dns or CoreDNS,
resolves the service’s hostname to a unique non-routable virtual IP (VIP),
if it is a service of type
kube-proxy on each node
maps this VIP to a set of pods of the service, and forwards the traffic
to one of them selected at random. When using a service mesh, the
sidecar works similarly to the
kube-proxy as far as traffic forwarding
The following diagram depicts the role of DNS today:
Problems posed by DNS
While the role of DNS within the service mesh may seem insignificant, it has consistently stood in the way of expanding the mesh to VMs and enabling seamless multicluster access.
VM access to Kubernetes services
Consider the case of a VM with a sidecar. As shown in the illustration below, applications on the VM look up the IP addresses of services inside the Kubernetes cluster as they typically have no access to the cluster’s DNS server.
It is technically possible to use
kube-dns as a name server on the VM if one is
willing to engage in some convoluted workarounds involving
external exposure of
NodePort services: assuming you
manage to convince your cluster administrator to do so. Even so, you are
opening the door to a host of security
the end of the day, these are point solutions that are typically out
of scope for those with limited organizational capability and domain
External TCP services without VIPs
It is not just the VMs in the mesh that suffer from the DNS issue. For
the sidecar to accurately distinguish traffic between two different
TCP services that are outside the mesh, the services must be on
different ports or they need to have a globally unique VIP, much like
clusterIP assigned to Kubernetes services. But what if there is
no VIP? Cloud hosted services like hosted databases, typically do not
have a VIP. Instead, the provider’s DNS server returns one of the
instance IPs that can then be directly accessed by the
application. For example, consider the two service entries below,
pointing to two different AWS RDS services:
apiVersion: networking.istio.io/v1alpha3 kind: ServiceEntry metadata: name: db1 namespace: ns1 spec: hosts: - mysql-instance1.us-east-1.rds.amazonaws.com ports: - name: mysql number: 3306 protocol: TCP resolution: DNS --- apiVersion: networking.istio.io/v1alpha3 kind: ServiceEntry metadata: name: db2 namespace: ns1 spec: hosts: - mysql-instance2.us-east-1.rds.amazonaws.com ports: - name: mysql number: 3306 protocol: TCP resolution: DNS
The sidecar has a single listener on
0.0.0.0:3306 that looks up the
IP address of
mysql-instance1.us-east1.rds.amazonaws.com from public
DNS servers and forwards traffic to it. It cannot route traffic to
db2 as it has no way of distinguishing whether traffic arriving at
0.0.0.0:3306 is bound for
db2. The only way to accomplish
this is to set the resolution to
NONE causing the sidecar to
blindly forward any traffic on port
3306 to the original IP
requested by the application. This is akin to punching a hole in the
firewall allowing all traffic to port
3306 irrespective of the
destination IP. To get traffic flowing, you are now forced to
compromise on the security posture of your system.
Resolving DNS for services in remote clusters
The DNS limitations of a multicluster mesh are well known. Services in one cluster cannot lookup the IP addresses of services in other clusters, without clunky workarounds such as creating stub services in the caller namespace.
Taking control of DNS
All in all, DNS has been a thorny issue in Istio for a while. It was time to slay the beast. We (the Istio networking team) decided to tackle the problem once and for all in a way that is completely transparent to you, the end user. Our first attempt involved utilizing Envoy’s DNS proxy. It turned out to be very unreliable, and disappointing overall due to the general lack of sophistication in the c-ares DNS library used by Envoy. Determined to solve the problem, we decided to implement the DNS proxy in the Istio sidecar agent, written in Go. We were able to optimize the implementation to handle all the scenarios that we wanted to tackle without compromising on scale and stability. The Go DNS library we use is the same one used by scalable DNS implementations such as CoreDNS, Consul, Mesos, etc. It has been battle tested in production for scale and stability.
Starting with Istio 1.8, the Istio agent on the sidecar will ship with
a caching DNS proxy, programmed dynamically by Istiod. Istiod pushes
the hostname-to-IP-address mappings for all the services that the
application may access based on the Kubernetes services and service
entries in the cluster. DNS lookup queries from the application are
transparently intercepted and served by the Istio agent in the pod or
VM. If the query is for a service within the mesh, irrespective of
the cluster that the service is in, the agent responds directly to the
application. If not, it forwards the query to the upstream name
servers defined in
/etc/resolv.conf. The following diagram depicts
the interactions that occur when an application tries to access a
service using its hostname.
As you will see in the following sections, the DNS proxying feature has had an enormous impact across many aspects of Istio.
Reduced load on your DNS servers w/ faster resolution
The load on your cluster’s Kubernetes DNS server drops drastically as almost all DNS queries are resolved within the pod by Istio. The bigger the footprint of mesh on a cluster, the lesser the load on your DNS servers. Implementing our own DNS proxy in the Istio agent has allowed us to implement cool optimizations such as CoreDNS auto-path without the correctness issues that CoreDNS currently faces.
To understand the impact of this optimization, lets take a simple DNS
lookup scenario, in a standard Kubernetes cluster without any custom
DNS setup for pods - i.e., with the default setting of
When your application starts a DNS lookup for
productpage.ns1.svc.cluster.local, it appends the DNS search
ns1.svc.cluster.local) as part
of the DNS query, before querying the host as-is. As a result, the
first DNS query that is actually sent out will look like
productpage.ns1.svc.cluster.local.ns1.svc.cluster.local, which will
inevitably fail DNS resolution when Istio is not involved. If your
/etc/resolv.conf has 5 search namespaces, the application will send
two DNS queries for each search namespace, one for the IPv4
and another for the IPv6
AAAA record, and then a final pair of
queries with the exact hostname used in the code. Before establishing the
connection, the application performs 12 DNS lookup queries for each host!
With Istio’s implementation of the CoreDNS style auto-path technique,
the sidecar agent will detect the real hostname being queried within
the first query and return a
cname record to
productpage.ns1.svc.cluster.local as part of this DNS response, as
well as the
A/AAAA record for
productpage.ns1.svc.cluster.local. The application receiving this
response can now extract the IP address immediately and proceed to
establishing a TCP connection to that IP. The smart DNS proxy in the
Istio agent dramatically cuts down the number of DNS queries from 12
to just 2!
VMs to Kubernetes integration
Since the Istio agent performs local DNS resolution for services
within the mesh, DNS lookup queries for Kubernetes services from VMs will now
succeed without requiring clunky workarounds for exposing
outside the cluster. The ability to seamlessly resolve internal
services in a cluster will now simplify your monolith to microservice
journey, as the monolith on VMs can now access microservices on
Kubernetes without additional levels of indirection via API gateways.
Automatic VIP allocation where possible
You may ask, how does this DNS functionality in the agent solve the problem of distinguishing between multiple external TCP services without VIPs on the same port?
Taking inspiration from Kubernetes, Istio will now automatically
allocate non-routable VIPs (from the Class E subnet) to such services
as long as they do not use a wildcard host. The Istio agent on the
sidecar will use the VIPs as responses to the DNS lookup queries from
the application. Envoy can now clearly distinguish traffic bound for
each external TCP service and forward it to the right target. With the
introduction of the DNS proxying, you will no longer need to use
resolution: NONE for non-wildcard TCP services, improving your
overall security posture. Istio cannot help much with wildcard
external services (e.g.,
*.us-east1.rds.amazonaws.com). You will
have to resort to NONE resolution mode to handle such services.
Multicluster DNS lookup
For the adventurous lot, attempting to weave a multicluster mesh where applications directly call internal services of a namespace in a remote cluster, the DNS proxy functionality comes in quite handy. Your applications can resolve Kubernetes services on any cluster in any namespace, without the need to create stub Kubernetes services in every cluster.
The benefits of the DNS proxy extend beyond the multicluster models that are currently described in Istio today. At Tetrate, we use this mechanism extensively in our customers’ multicluster deployments to enable sidecars to resolve DNS for hosts exposed at ingress gateways of all the clusters in a mesh, and access them over mutual TLS.
The problems caused by lack of control over DNS have often been overlooked and ignored in its entirety when it comes to weaving a mesh across many clusters, different environments, and integrating external services. The introduction of a caching DNS proxy in the Istio sidecar agent solves these issues. Exercising control over the application’s DNS resolution allows Istio to accurately identify the target service to which traffic is bound, and enhance the overall security, routing, and telemetry posture in Istio within and across clusters.
Smart DNS proxying is enabled in the
profile in Istio 1.8. Please try it out!
